CH9: Diagnostics

MAN0575-04-EN

PAGE 75 of 97

© Horner APG.This drawing is the property of Horner APG. And shall not be disclosed or reproduced except as specifically authorised.

Profibus Modules User Manual

EO 09-0009

Message for Write via DPV1
Message header

Rx = 3 (always)

Tx = 255

Ln = (calculated)

Nr = 0 .. 255

A = 17

F = 0

B = 0

E = 0

Telegram header

Meaning for DPV1

Value range

Device Adr

Station address of the Slave 0 .. 126

Data Area

Unused

0

Data Address

Slot

0 .. 254

Data Index

Index

0 .. 255

Data Count

Data Count

1 .. 240

Data Type

Data Type

10

Function

Write

2

Table 19: Message Monitor – Example DPV 1 Write
