background image

MIX577

07 APR 2006

Page 1










Refer to SmartStix Analog Programming Guide (MAN0703) at

www.HornerOCS.com

.

1 SPECIFICATIONS

ANALOG IN

Number of input
points

4

Conversion Time

5mS for all Channels

Input Ranges

±5V, ±10V DC

4-20mA, ±20mA DC

Isolation

1000V DC

IEC61010-1 300V RMS

Resolution

14 bits

Isolation Method

Magnetic

Accuracy, 25°C

0.3%

Maximum
Continuous
Overload

±10V: 150VAC

±20mA: ±30mA,
Clamped at ±6V

Input Impedance

V: 1 Megohm

mA: 150 Ohms

Programmable Filter
Time Constants

0.01 to 1.28 Seconds

Register Value for
Nominal Full Scale

32000

Filter Modes

Running Average or

Adaptive

ANALOG OUT
Number of output
points

2

Isolation

1000V DC

IEC61010-1 300V RMS

Input Ranges

±5, ±10V DC

4-20mA, ±20mA DC

Isolation Method

Magnetic

Resolution

14 bits

Output Clamp

±12V, 600Wpk

Accuracy, 25°C

0.3%

Load Resistance

V: 600 Min

mA: 500 Max

Register Value for
Nominal Full Scale

32000

GENERAL
Required Power
(Steady State)

3.6W

(150ma @ 24VDC)

Operating
Temperature

0

° to 55° C

Operating and
Storage Humidity

5 to 95% Non-

condensing

Required Power
(Inrush)

8A @ 24VDC for

1ms

Altitude for use

Up to 2,000m

Storage Temperature

-25

° to 70° C

Pollution degree

2 or lower

Cooling method

Self-cooling

Atmosphere

Free from corrosive

gases and excessive

dust

Weight

8.40 oz. (238 g)




MAN0708-01

Analog I/O Module

HE559MIX577

4 Input Channels

2 Output Channels

±5V / ±10V / 4-20mA / ±20mA

CsCAN

SmartStix
