Horner APG SmartStix HE559MIX977 User Manual

Smartstix, Analog i/o module

background image

MAN0561-02

27 FEB 2007

PAGE 1

All information subject to change without notice.










Refer to SmartStix Analog Programming Guide (MAN0703) at

www.HornerOCS.com

.


1 SPECIFICATIONS

ANALOG IN

Number of input points

8

Conversion Time

10ms for all

Channels

Input Ranges

±5V, ±10V DC

4-20mA, ±20mA DC

Isolation

1000V DC

IEC61010-1 300V

RMS

Isolation Method

Magnetic

Resolution

14 bits

Additional error for

temperatures other than 25°C

0.01% /

°C

Accuracy, 25°C

0.1%

Maximum Continuous

Overload

±10V: 150VAC

±20mA: ±30mA,
Clamped at ±6V

Input Impedance

V: 1 Megohm

mA: 150 Ohms

Programmable Filter Time

Constants

0.01 to 1.28 Seconds

Register Value for

Nominal Full Scale

±32000

Filter Modes

Running Average or

Adaptive

ANALOG OUT

Number of output

points

4

Isolation

1000V DC

IEC61010-1 300V

RMS

Output Ranges

±5, ±10V DC

4-20mA, ±20mA DC

Isolation Method

Magnetic

Resolution

14 bits

Output Clamp

±12V, 600Wpk

Accuracy, 25°C

0.1%

Register Value for Nominal

Full Scale

±32000

Load Resistance

V: 600 Min

mA: 500 Max

Max Output current, mA

mode

3 channels driving 20mA

max output loads

Output Characteristic

Sourcing

GENERAL

Required Power

(Steady State)

3.6W

(150ma @ 24VDC)

Operating Temperature

0

° to 55° C

Required Power

(Inrush)

8A @ 24VDC for 1ms

Operating and Storage

Humidity

5 to 95% Non-

condensing

Storage Temperature

-25

° to 70° C

Altitude for use

Up to 2,000m

Atmosphere

Free from corrosive gases

and excessive dust

Pollution degree

2 or lower

Cooling method

Self-cooling

Weight

9 oz. (256g)



Analog I/O Module

HE559MIX977

8 Input Channels

4 Sourcing Output Channels
±5V / ±10V / 4-20mA / ±20mA

CsCAN

SmartStix
