Director Element Manager user guide

97

Configuring switch binding

For complete procedures on configuring this optional feature, see

SANtegrity features

” on

page 187.

Configuring SANtegrity Authentication

The Security feature is accessed from the SANtegrity Authentication dialog box in the individual

element managers applications. The element manager lets you manage one device at a time.
Access the SANtegrity Authentication dialog box by selecting Configure > SANtegrity

Authentication. The Configure Security Authentication dialog box is displayed (

Figure 33

).

Figure 33

Configure Security Authentication dialog box

To access the SANtegrity Authentication, one user must have the security administrator privilege. If

not, the Security tab is hidden. By default, the security administrator user group is displayed when

installing this feature.
The upper right part of the window shows the main working area, where the security administrator

configures the authentication security settings.
The lower left part of the window shows the regular master log and the lower right part of the

window shows the security log.

NOTE:

The SANtegrity Authentication dialog box is only available to the security administrator so

the Security Log is only available to the security administrator.

Change the default size of the display by placing the cursor on the divider until a double arrow is

displayed. Click and drag the adjoining divider to resize the window. You can also show or hide an

area by clicking the left or right arrow on the divider.
