Director Element Manager user guide 187

NOTE:

Clicking the check box when it contains a check mark removes the check mark and

allows a host program to change configuration and connectivity parameters on the switch.

2.

If you have finished configuring the switch, back up the configuration data. For more

information, see

Backing up and restoring configuration

” on page 172.

SANtegrity features

SANtegrity includes a set of features that enhance security in SANs that contain a large and mixed

group of fabrics and attached devices. Through these features, you can allow or prohibit switch

attachment to fabrics and device attachment to switches. These features are enabled by purchasing

a feature key, then enabling the key through the Configure Feature Key dialog box. For general

instructions for enabling a feature key, see ”

Configuring the feature key

” on page 136.

SANtegrity binding features include:

Fabric Binding

, page 187

Switch Binding

, page 188

Enterprise Fabric Mode

, page 191

Fabric Binding

The fabric binding feature is managed through the Fabric Binding option, which is available

through the Fabrics menu in HAFM when the Fabrics tab is selected. Using Fabric Binding, you

can allow specific switches to attach to specific fabrics in the SAN. This provides security from

accidental fabric merges and potential fabric disruption when fabrics become segmented because

they cannot merge.

Enable/disable and Online State functions

For Fabric Binding to function, specific operating parameters and optional features must be

enabled. Also, there are specific requirements for disabling these parameters and features when the

switch is off line or on line.
Be aware of the following:

Because switches are bound to a fabric by World Wide Name (WWN) and domain ID, the

Insistent Domain ID option in the Configure Switch Parameters dialog box is automatically

enabled if Fabric Binding is enabled.

If Fabric Binding is enabled and the switch is on line, you cannot disable Insistent Domain ID.

If Fabric Binding is enabled and the director or switch is off line, you can disable Insistent

Domain ID, but this will disable Fabric Binding.

You cannot disable Fabric Binding or Switch Binding if Enterprise Fabric Mode is enabled.

However, if Enterprise Fabric Mode is disabled, you can disable Fabric Binding, Switch Binding,

or both.

For more information about how to enable, disable, and configure fabric binding, see the Fabric

Binding section of the HP StorageWorks HA-Fabric Manager user guide.
