Optional features

184

Configuring the FICON Management Server

NOTE:

The optional FICON Management Server feature must be installed in order to perform this

procedure.

To configure FICON management server:

1.

Select Configure > FICON Management Server > Parameters.

The Configure FICON Management Server dialog box is displayed, as shown in

Figure 87

.

Figure 87

Configure FICON Management Server Parameters dialog box

2.

Click Director Clock Alert Mode to enable or disable switch clock alert mode.

When a check mark is displayed, the alert mode is enabled.

3.

Click Host Control Prohibited to allow or prohibit host control.

When a check mark is displayed, host control is prohibited.

4.

Click Programmed offline state control to allow or prohibit off line state control.

When a check mark is displayed, programmed control of the off line state is allowed.

5.

If necessary, click a code page from the Code Page list.

6.

Select a Missing Interrupt Handler Timeout (MIHPTO) from the list.

7.

Click Activate.

FICON Management Server parameters

Enable Management Server—Adds a check mark and enable the management server. Click

the check box to remove the check mark and disable this feature.

Parameters—Click this option to display the Configure FICON Management Server dialog

box, which includes the following options:

Switch Clock Alert Mode—Displays a check mark and enable clock alert mode. If this is

enabled, the following occurs when users set the date and time through the Configure Date

and Time dialog box (Configure menu):
• If you enable Periodic Date/Time Synchronization, an error message is displayed

indicating that Clock Alert Mode must be cleared to enable automatic synchronization of

the date and time.
