Director Element Manager user guide 123

Type (open systems management style only)
Set All to G_Ports—Sets all fields in this column to G_Port and configures all ports on the

switch as G_Ports.

Set All to F_Ports—Sets all fields in this column to F_Port and configures all ports on the

switch as F_Ports.

Set All to E_Ports—Sets all fields in this column to E_Port and configures all ports on the

switch as E_Ports.

Speed
Set All To 1 Gb/sec—Sets the port optics to a 1 Gb/s data rate.
Set All To 2 Gb/sec—Sets the port optics to a 2 Gb/s data rate.
Set All To Negotiate—Allows the port to negotiate the data rate with the attached device.

NOTE:

Your director model, firmware, and port cards may not allow 2 Gb/s data speeds.

Port Binding
Bind All WWNs—Places a check mark in all check boxes in this column and binds each port

to the device with the WWN or nickname entered in the Bound WWN column for that port.

Unbind All WWNs—Removes check marks in all check boxes in this column. A device with

any WWN can attach to all ports.

Bind All Ports to Attached WWN—Places a check mark in all check boxes in this column and

binds each port to the device currently attached to that port. The Bound WWN column will

display that device’s WWN.

Bind Port to Attached WWN—Places a check mark in the check box for the port where you

clicked to display the menu. This binds that port to the device currently attached to that port.

The Bound WWN column will display that device’s WWN.

Clear All Bound WWNs—Clears all WWNs listed in the Bound WWN column.

Bound WWN
Bind All WWNs—Places a check mark in all check boxes in this column and binds each port

to the device with the WWN or nickname entered in the Bound WWN column for that port.

Unbind All WWNs—Removes check marks in all check boxes in this column. A device with

any WWN can attach to all ports.

Bind All Ports to Attached WWN—Places a check mark in all check boxes in this column and

binds each port to the device currently attached to that port. The Bound WWN column will

display that device’s WWN.

Bind Port to Attached WWN—Places a check mark in the check box for the port where you

clicked to display the menu. This binds that port to the device currently attached to that port.

The Bound WWN column will display that device’s WWN.

Clear All Bound WWNs—Clears all WWNs listed in the Bound WWN column.

Configuring ports (Open Systems management style)

To configure ports in Open Systems management style:
