Monitoring and managing the director 70
Figure 24 Clear Threshold Alert(s) dialog box
• Clear Zoning Enforcement Alert(s)—Select the Clear Zoning Enforcement Alert(s) option when
you right-click a port row in the Hardware View and the Port List View to display the Clear
Zoning Enforcement Alert(s) dialog box. The Clear Zoning Enforcements Alerts dialog box lets
you acknowledge the attention indicator and hide the icon in all views, by selecting either All
ports on paddle pair or All ports on Director. After you clear these alerts, the Zoning
Enforcement field that displays in the Port Properties dialog box for Directordisplays either
Soft
Zoning
or
Hard Zoning
. The Zoning Enforcement field that displays for switches
displays
N/A
.
Port List view
Display the Port List view as shown in Figure 25 in the View panel by selecting the Port List option
from the view tabs.
Figure 25 Port List view
The Port List view displays the following information on all ports that can be installed in the director.
All information is updated automatically.
• Port #—The physical port number, from 0–63 on the Director 2/64 and 0–127 and 132–143
on the Director 2/140. Note that for the Director 2/140, ports 128–131 are internal ports and
not available for external connections.
