IP—The IP address.

Role—The role of the user.

Interface—The interface.

Configuring ports

Use the Configure Ports dialog box to configure names, blocked and unblocked state, 10–100 km

extended distance buffering, enable or disable LIN alerts for ports, port type, port speed, port

binding, and the bound WWN.

NOTE:

The Configure Ports dialog box is different for FICON and Open Systems management

styles. Those options available in Open Systems management style only are labeled as such.

The Port Binding feature must be installed before the Port Binding and Bound WWN columns can be

used. See ”

Configuring the Open Systems Management Server

” on page 136 to install the Port

Binding feature.
Port configuration data is stored in NV-RAM on the switch. Configure data in the following columns

of the Configure Ports dialog box:

Port #—You cannot edit this field. The physical port number, from 0-63 on the Director 2/64,

and 0-127 and 132-143 on the Director 2/140. Note that for the Director 2/140, ports

128-131 are internal ports and not available for external connections.

Name (Open Systems management style only)—Enter a name for the port. The port names

display in the Port Properties dialog box and elsewhere in the Element Manager to identify the

port.

NOTE:

To identify port numbers for which you want to provide names, place the mouse pointer

over the ports in the Hardware view. As you move over a port, a message is displayed that

identifies the slot number where the port is installed.

To name ports in FICON Management Style, use the Configure Addresses dialog box.

Blocked (Open Systems Management style only)—Placing a check mark in the check boxes of

this column blocks the operation of the port.
To block ports in FICON Management Style, use the Configure Addresses dialog box.

10-100Km—This column is for extended distance buffering. You can enable extended distance

for a port even if it is not an extended distance port. However, enabling extended distance

buffering on a port disables the ability for the port to send broadcast traffic. When you select

this option, the port can support up to 60 buffer-to-buffer credits (BB_Credits) to handle link

distances up to 100 km. If this option is not enabled, the port uses the BB_Credit (1–60)

configured through the Configure Fabric Parameters dialog box.
If a device is connected and logged in to the fabric when extended distance is enabled or

disabled on the corresponding port, the switch will send OLS for 5 ms to force the device to log

in again and obtain the new BB_Credit value set for the port.
