Director Element Manager user guide 185
• If you manually set the date and time (Periodic Date/Time Synchronization is not
enabled), a confirmation dialog box will display. You must click OK on that dialog box to
continue manual configuration.
• Host Control Prohibited—Displays a check mark and prohibit a host management program
from changing configuration and connectivity parameters on the director. In this case, the
host program will have read authorization only and cannot make changes. When the check
mark is not displayed, a host program can change configuration and connectivity
parameters on the director.
• Programmed offline state control—Displays a check mark and enable a host management
program to control the director’s off line and on line state. When a check mark is not
displayed, a host program cannot set the director on line or off line.
•
Code Page—Consider the language required for the port name displayed on the HAFM
appliance. Language support is provided through character set 697 for all extended
binary-coded decimal interchange code (EBCDIC) pages.
When planning the installation, select the EBCDIC code page for displaying host-assigned port
names or the CUP name. As an example, if the code page for Italy is selected and a port name
is assigned in Italian by the host management program, then the Italian language port name will
display in the Element Manager.
This field lists the code pages that are available for configuration. The default code page is
United States/Canada 00037. See the following table for other code pages:
•
Missing Interrupt Handler Timeout (MIHPTO)—This dialog box displays supported
timeout values. The MIH Timeout is stored on the Switch, but is not used by the Switch. The host
uses this value and retrieves the value from the Switch using FICON, Control Unit Port (CUP).
The list displays the valid timeout values. These times are consistent with CLI commands. CLI uses
FICON Management Server Configuration for these commands.
Table 10
Available code pages
Code Page
Name
Code Page
Hexadecimal
CPGID
United
States/Canada
00037
0025
Germany/
Austria
00273
0111
Brazil
00275
0113
Italy
00280
0118
Japan
00281
0119
Spain/Latin
America
00284
011C
United Kingdom
00285
011D
France
00297
0129
International #5
00500
01F4
