Element Manager Overview 46
Switch status symbols
Table 3 lists symbols can appear on the Status Bar:
Closing the Element Manager
To close the Element Manager, use one of the following methods:
• Select Product > Close.
• Click the X at the top right corner of the Element Manager window.
• Double-click the icon at the top left corner of the Element Manager window, or right-click the
icon and click Close on the menu.
Table 3 Status Bar symbols
Status bar
symbol
Switch status table text Description
Green circle
Fully Operational All components and installed ports are operational; no
failures.
Yellow triangle
Redundant Failure A redundant component has failed, such as a power
supply, and the backup component has taken over
operation.
Minor Failure A failure occurred, causing a decrease in the operational
ability of the switch. Normal switching operations are not
affected.
Red diamond
with yellow
background
NOT OPERATIONAL A critical failure prevents the switch from performing
fundamental switching operations.
All fans have failed.
An installed port has failed.
Both power supplies have failed.
Gray square
Never Connected
Link Timeout
Protocol Mismatch
Duplicate Session
Unknown Network Address
Incorrect Product Type
Switch status is unknown. This occurs if the Ethernet
network connection between the HAFM appliance and
the switch cannot be established or if the CTP fails. See
the No Link Status bullet description in Table on page 50
for details on the status table text.
