NOTE:

The HP Storage mpx Manager software is available as a separate download or as

part of the HP Storage Data Migration Utilities kit which includes additional data migration
tools.

The MPX200 chassis contains one or two router blades, two PCMs, and a mid-plane. There are
two types of router blades: a 4-port 1-GbE blade and a 2-port 10-GbE/2-port 1-GbE blade. Both
blade options include two 8-Gb/s FC ports. MPX200 dual-blade configurations provide for high
availability with failover between blades.

NOTE:

Each PCM has three variable-speed fans that provide power and cooling. You can remove

and replace a PCM at any time. To ensure that the MPX200 chassis remains operational, there
must be at least one functioning PCM. Each PCM is capable of powering two blades. The PCM
cools the corresponding blade; therefore, when you remove a PCM, you must replace it within 7
minutes or the blade will shut down due to an over-temperature condition.

Table 2 (page 13)

lists the MPX200 options.

Table 2 MPX200 options

Order with

Option includes

Option

Up to four P6000 EVA, 3PAR StoreServ
10000/7000, 3PAR T-Class/F-Class, or

HP MPX200 1GbE Base
Chassis

One chassis

One 1-GbE blade with four
1-GbE iSCSI ports and two
8-Gb/s FC ports

XP24000/20000 storage systems, or order
separately to upgrade existing storage systems

Rail kit

Accessory kit

Documentation

Redundant power supplies

An MPX200 base chassis and up to four P6000
EVA, 3PAR StoreServ 10000/7000, 3PAR

HP MPX200 1 GbE
Upgrade Blade

One 1-GbE blade with four
1-GbE iSCSI ports and two
8-Gb/s FC ports

T-Class/F-Class, or XP24000/20000 storage
systems, or to upgrade existing storage systems to
provide high-availability multipath connectivity

Accessory kit

Documentation

Up to four P6000 EVA, 3PAR StoreServ
10000/7000, 3PAR T-Class/F-Class, or

HP MPX200 10-1GbE Base
Chassis

One chassis

One 10-GbE/1-GbE blade with
two 10-GbE and two 1-GbE

XP24000/20000 storage systems, or order
separately to upgrade existing storage systems

iSCSI ports, and two 8-Gb/s FC
ports

Rail kit

Accessory kit

Documentation

Redundant power supplies

An MPX200 base chassis and P6000 EVA, 3PAR
StoreServ 10000/7000, 3PAR T-Class/F-Class, or

HP MPX200 10-1GbE
Upgrade Blade

One 10-GbE/1-GbE blade with
two 10-GbE and two 1-GbE

XP24000/20000 storage systems, or to upgrade

iSCSI ports, and two 8-Gb/s FC
ports.

up to four existing storage systems to provide
high-availability multipath connectivity

Accessory kit

Documentation

Includes the license to enable FCIP
functionality in one out of two bays
(slots) in an MPX200 chassis.

HP MPX200 Half Chassis
FCIP License

MPX200 storage system support
