Page 85
- 75 -
4.6.2. How to set the flow rate unit
Description
z
Select the unit of flow rate.
z
Metric system
Flow rate···················· L/s (factory set), L/min, L/h, ML/d, m
3
/s, m
3
/min, m
3
/h, Mm
3
/d, BBL/s, BBL/min,
BBL/h, MBBL/d
z
Inch system
Flow rate···················· gal/s, gal/min, gal/h, Mgal/d, ft
3
/s, ft
3
/min, ft
3
/h, Mft
3
/d, BBL/s, BBL/min, BBL/h,
MBBL/d
For actual keying, refer to the typical operation indicated below. Set the parameter protection to OFF beforehand
(Section 4.4.1).
Typical operation Set the flow rate unit to [m
3
/h].
Keying order
Description
Indication
ź
Pressed 3 times to indicate "MEASURE SETUP".
MEASURE SETUP
ENT
ź
Pressed to indicate "SYSTEM UNIT".
SYSTEM UNIT
METRIC
ź
Pressed to indicate "FLOW UNIT".
FLOW UNIT
L/S
ENT
ź
Pressed to blink.
FLOW UNIT
L/S
ź
Pressed 6 times to select "m
3
/h".
FLOW UNIT
m3/h
Pressed to register it.
FLOW UNIT
½½ COMPLETE ½½
Ļ
ENT
ź
ź
ź
ź
--- "m
3
/h" registered.---
FLOW UNIT
m3/h
ESC
Press
ESC
key once, and
key twice to resume
the measurement mode.
0.000 m/s
0.000 m3/h
