Table 42 – Brocade Virtual ADX Server Load Balancing Guide (Supporting ADX v03.1.00) User Manual
Page 390

374
Brocade Virtual ADX Server Load Balancing Guide
53-1003247-01
Displaying real server information and statistics
B
TABLE 42
Real server detail information
Field
Description
Port
The TCP/UDP port name or number. This field can have one of the
following values:
•
default
•
dns – The well-known name for port 53
•
ftp – The well-known name for port 21. (Ports 20 and 21 both are
FTP ports but on the Brocade Virtual ADX, the name “ftp”
corresponds to port 21.)
•
http – The well-known name for port 80
•
imap4 – The well-known name for port 143
•
ldap – The well-known name for port 389
•
nntp – The well-known name for port 119
•
ntp – The well-known name for port 123
•
pop2 – The well-known name for port 109
•
pop3 – The well-known name for port 110
•
radius – The well-known name for udp port 1812
•
smtp – The well-known name for port 25
•
snmp – The well-known name for port 161
•
ssl – The well-known name for port 443
•
telnet – The well-known name for port 23
•
tftp – The well-known name for port 69
•
number – The port number, if the port is not one of those listed
above
St
The state of the port. The state can be one of the following:
•
enabled
•
failed
•
test
•
suspect
•
graceful shutdown
•
active
•
unbnd
NOTE: If the state is unbnd, you have not bound the port to a virtual
server port.
