Displaying real server information and statistics
B
State
The state of the real server, based on Layer 3 health checks. The state
can be one of the following states, also listed next to "Server State" at
the top of the show server real display:
•
ACT: Active
•
ENB: Enabled
•
FAL: Failed
•
TST: Test
•
DIS: Disabled
•
UNK: Unknown
•
UNB: Unbind
•
AWU: Await-unbind
•
AWD: Await-delete
NOTE: HLD: Held-down. The value in this field is based on the results of
Layer 3 health checks, if enabled. The real server state can also
be seen in the State column in the show server session display.
To display the server state based on Layer 3 health checks, refer
to the State field in the show server session display.
Cost
The hop cost to reach the remote or cache server.
Mac
The real server MAC address or next hop MAC address for remote
servers.
Wt
The weight assigned to this server. The weight applies only if the
predictor (load balancing method) is “weighted”. Refer to
application ports from virtual servers”
SrcNAT
The configured and operational states of the source NAT feature. The
two states are separated by a colon (:). The configured state is shown
first, followed by the operational state. Each state can have one of the
following values:
•
0 – Disabled
•
1 – Enabled
DestNAT
The configured and operational states of the destination NAT feature.
The two states are separated by a colon (:). The configured state is
shown first, followed by the operational state. Each state can have one
of the following values:
•
0 – Disabled
•
1 – Enabled
Serv-Rsts
Number of resets sent by the real server for a TCP SYN packet forwarded
by Brocade Virtual ADX.
Rx throughput
Rate at which packets are received expressed in Kbps.
Tx throughput
Rate at which packets are transmitted expressed in Kbps.
tcp conn rate
Rate at which the server receives TCP connections.
udp conn rate
Rate at which a real or remote server receives UDP connections.
Use local conn
Not currently supported/valid for Brocade Virtual ADX.
TABLE 41
Real server information (Continued)
Field
Description
