4. Driver Card Parameters
No. Parameter
name
Default value
(Reference)
Input
range
Unit Remarks
1
Type (upper) (Manufacturing
information)
Space Reference
only
For adjustment by the manufacturer
2
Type (middle) (Manufacturing
information)
Space Reference
only
For adjustment by the manufacturer
3
Type (lower) (Manufacturing
information)
Space Reference
only
For adjustment by the manufacturer
4
Manufacturing data 4
(Manufacturing information)
Space Reference
only
For adjustment by the manufacturer
5
Manufacturing data 5
(Manufacturing information)
Space Reference
only
For adjustment by the manufacturer
6
Manufacturing data 6
(Manufacturing information)
Space Reference
only
For adjustment by the manufacturer
7
Manufacturing data 7
(Manufacturing information)
Space Reference
only
For adjustment by the manufacturer
8
Board type (Function
information)
30 Reference
only
For adjustment by the manufacturer
9
Function information 01 (hard):
Encoder support information
(upper word)
0000H Reference
only
Encoder ID bit
pattern
For adjustment by the manufacturer
10 Function information 02 (hard):
Encoder support information
(lower word)
0003H Reference
only
Encoder ID bit
pattern
For adjustment by the manufacturer
11 Function information 03 (hard):
Hardware support information
word 0
0001H Reference
only
For adjustment by the manufacturer
12 Function information 04 (hard):
For future expansion
0000H Reference
only
For adjustment by the manufacturer
13 Function information 05 (hard):
For future expansion
0000H Reference
only
For adjustment by the manufacturer
14 Function information 06 (hard):
For future expansion
0000H Reference
only
For adjustment by the manufacturer
15 Function information 07 (soft):
Motor support information
(upper word)
0000H Reference
only
Motor ID bit
pattern
For adjustment by the manufacturer
16 Function information 08 (soft):
Motor support information
(lower word)
003FH Reference
only
Motor ID bit
pattern
For adjustment by the manufacturer
17 Function information 09 (soft):
Encoder support information
(upper word)
0000H Reference
only
Encoder ID bit
pattern
For adjustment by the manufacturer
18 Function information 10 (soft):
Encoder support information
(lower word)
0003H Reference
only
Encoder ID bit
pattern
For adjustment by the manufacturer
19 Function information 11 (soft):
Software support information
word 0
(For future expansion = Change
prohibited)
0000H Reference
only
For adjustment by the manufacturer
20 Function information 12 (soft):
Software version information
0001H Reference
only
For adjustment by the manufacturer
21 Function information 13 (soft):
For future expansion
0000H Reference
only
For adjustment by the manufacturer
22 Function information 14 (soft):
System log control word
0000H Reference
only
For adjustment by the manufacturer
23 Configuration
information
01:
Configured capacity (rated
motor output)
003CH Reference
only
For adjustment by the manufacturer
24 Configuration
information
02:
Configured voltage (motor
voltage)
00C8H Reference
only
For adjustment by the manufacturer
