204
Part 4 Commands
z STRH (Convert character string; hexadecimal)
Command, declaration
Extension condition
(LD, A, O, AB, OB)
Input condition
(I/O, flag)
Command,
declaration
Operand 1 Operand 2
Output
(Output, flag)
Optional Optional STRH
Column
number
Data CC
[Function] Copy to the column specified in operand 1 a hexadecimal character string converted from the
data specified in operand 2.
Only the integer part will be adjusted to the length set by a SLEN command.
If the data exceeds the specified length, it will be cut off at the length set by a SLEN
command.
If the entire data has been converted within the length set by a SLEN command, the output
will turn ON.
(Note) If the data specified in operand 2 is a negative value, eight columns will be required to covert
the entire data.
[Example] SLEN 5 Set a format consisting of five integer digits.
STRH 1 255 The following values will be set in columns 1 to 5:
1 2 3 4 5
E F
LET 1 10 Assign 10 to variable 1.
LET 102 987.6543 Assign 987.6543 to variable 102.
SLEN 2.3 Set a length consisting of two integer digits and three
decimal digits.
STRH *1 *102 The following values will be set in columns 10 and 11:
10 11
D B
³´LQWKH6/(1FRPPDQGDQG³´LQYDULDEOH
which are the decimal part, will be ignored.
The integer part is express
HGDVµ'%¶LQKH[DGHFLPDO
Since the length is two digi WVKRZHYHU³´LQWKHWKLUG
digit will be cut off.
