Camera dimensions

PIKE Technical Manual V5.1.2

85

Cross section: M58-Mount

Figure 40: Pike M58-Mount dimensions (optional for Pike F-1100 and Pike F-1600)

optical: 20.5

Adjustment spacer

filter / protection glass

Q

4

6

.4

8

maximum

protrusion:
