Configuration of the camera
PIKE Technical Manual V5.1.2
374
Stored settings
The following table shows the settings stored inside a profile:
The user can specify which user profile will be loaded upon startup of the cam-
era.
This frees the user software from having to restore camera settings, that differ
from default, after every cold start. This can be especially helpful if third party
software is used which may not give easy access to certain advanced features or
may not provide efficient commands for quick writing of data blocks into the
camera.
Standard registers Standard registers

(Format_7)
Advanced registers
Cur_V_Frm_Rate

Cur_V_Mode

Cur_V_Format

ISO_Channel

ISO_Speed

BRIGHTNESS

AUTO_EXPOSURE (Target grey level)

SHARPNESS

WHITE_BALANCE (+ auto on/off)

HUE (+ hue on)

SATURATION (+ saturation on)

GAMMA (+ gamma on)

SHUTTER (+ auto on/off)

GAIN

TRIGGER_MODE

TRIGGER_POLARITY

TRIGGER_DELAY

ABS_GAIN
IMAGE_POSITION (AOI)

IMAGE_SIZE (AOI)

COLOR_CODING_ID

BYTES_PER_PACKET
TIMEBASE

EXTD_SHUTTER

IO_INP_CTRL

IO_OUTP_CTRL

IO_INTENA_DELAY

AUTOSHUTTER_CTRL

AUTOSHUTTER_LO

AUTOSHUTTER_HI

AUTOGAIN_CTRL

AUTOFNC_AOI (+ on/off)

COLOR_CORR (on/off + color correction
coefficients)

TRIGGER_DELAY

MIRROR_IMAGE

HIGH_SNR

LUT_CTRL (LutNo; ON_OFF is not saved;
up to 16 LUTs can be saved in 4 user sets)

SHDG_CTRL (on/off + ShowImage)

DEFERRED_TRANS (HoldImg +

NumOfImages)

CHANNEL_ADJUST_CTRL

CHANNEL_ADJUST_VALUE

ADV_CHN_ADJ_OFFSET

ADV_CHN_ADJ_OFFSET+1
Table 194: User profile: stored settings
