Input/output pin control
All input and output signals running over the camera I/O connector are con-
trolled by an advanced feature register.
Register Name Field Bit Description
0xF1000300 IO_INP_CTRL1 Presence_Inq [0] Indicates presence of this fea-
ture (read only)
--- [1..6] Reserved
Polarity [7] 0: Signal not inverted
1: Signal inverted
--- [8..10] Reserved
InputMode [11..15] Mode
see Table 26: Input routing on
page 118
--- [16..30] Reserved
PinState [31] RD: Current state of pin
0xF1000304 IO_INP_CTRL2 Same as
IO_INP_CTRL1
Table 25: Advanced register: Input control
