Configuration of the camera
PIKE Technical Manual V5.1.2
360
Sensor digitization taps (Pike F-1100/1600
only)
The sensor digitization taps fields DigitizationTaps [18..21] and SensorTaps
[22..25] allow to switch between single-tap and dual-tap mode of a multi-tap
sensor (Pike F-1100/1600). The settings are stored permanently within the
camera and do not depend on any user set.
•
To switch single-tap set bit [18..21] to 0.
•
To switch dual-tap set bit [18..21] to 1.
•
To get info how many taps are present read out bit [22..25].
– 0 indicates 1 tap.
– 1 indicates 2 taps.
Note
During the startup of the camera and if an error condition is
present, the LEDs behave as described in Chapter
Status LEDs
on page 94ff.
