Configuration of the camera
PIKE Technical Manual V5.1.2
368
Where to find time stamp, frame counter and trigger counter
in the image
Where to find all SIS values in the image
In the following table you find the position of all SIS values (byte for byte)
including the endianness of SIS values.
Figure 152: SIS in the image: time stamp, frame counter, trigger counter
CycleCounter [7..0] CycleCounter [15..8] CycleCounter [23..16] CycleCounter [31..24]
Byte 1 Byte 2 Byte 3 Byte 4
FrameCounter [7..0] FrameCounter [15..8] FrameCounter [23..16] FrameCounter [31..24]
Byte 5 Byte 6 Byte 7 Byte 8
TriggerCounter [7..0] TriggerCounter [15..8] TriggerCounter [23..16] TriggerCounter [31..24]
Byte 9 Byte 10 Byte 11 Byte 12
AoiLeft [7..0] AoiLeft [15..8] AoiTop [7..0] AoiTop [15..8]
Byte 13 Byte 14 Byte 15 Byte 16
AoiWidth [7..0] AoiWidth [15..8] AoiHeight [7..0] AoiHeight [15..8]
Byte 17 Byte 18 Byte 19 Byte 20
Shutter [7..0] Shutter [15..8] Shutter [23..16] Shutter [31..24]
Byte 21 Byte 22 Byte 23 Byte 24
Gain [7..0] Gain [15..8] Reserved [NULL] Reserved [NULL]
Byte 25 Byte 26 Byte 27 Byte 28
OutputState_1 [7..0] OutputState_2 [7..0] OutputState_3 [7..0] OutputState_4 [7..0]
Byte 29 Byte 30 Byte 31 Byte 32
InputState_1 [7..0] InputState_2 [7..0] Reserved [NULL] Reserved [NULL]
Byte 33 Byte 34 Byte 35 Byte 36
SequenceIndex [7..0] Reserved [NULL] ColorCoding [NULL] Reserved [NULL]
Byte 37 Byte 38 Byte 39 Byte 40
SerialNumber [7..0] SerialNumber [15..8] SerialNumber [23..16] SerialNumber [31..24]
Byte 41 Byte 42 Byte 43 Byte 44
SIS_UserValue [7..0] SIS_UserValue [15..8] SIS_UserValue [23..16] SIS_UserValue [31..24]
Byte45 Byte46 Byte47 Byte48
Table 189: SIS values (increasing order of transmitted pixels)
1 2 3 4 5 6 7 8 9 10 11 12 .. .. . .
     
  
Time stamp (Cycle counter)
Frame counter
Trigger counter
Bytes
Output line
of image
