Configuration of the camera
PIKE Technical Manual V5.1.2
361
Parameter-List Update
The parameter list is an array of address/data pairs which can be sent to the
camera in a single bus cycle.
Dependant on the parameter update mode the address/data pairs may become
active one by one or after the processing of the complete parameter list. A
parameter list may look like follows (the description is for your convenience):
Register Name Field Bit Description
0xF1100000 PARAMLIST_INFO Presence_Inq [0] Indicates presence of this feature
(read only)
--- [1..15] Reserved
BufferSize [16..31] Size of parameter list buffer in
bytes
0xF1101000
...
0xF1101nnn
PARAMLIST_BUFFER
Table 181: Advanced register: Parameter-List Update: parameter list
Address offset Data quadlet Description
0xF0F00608 0xE0000000 Set video format 7
0xF0F00604 0x00000000 Set video mode 0
0xF0F08008 0x00000000 Set image position
0xF0F0800C 0x028001E0 Set image size
0xF0F08044 0x04840484 Set BytePerPacket value
0xF0F0080C 0x80000100 Set shutter to 0x100
0xF0F00820 0x80000080 Set gain to 0x80
Table 182: Example: parameter list
Note

• The PARAMLIST_BUFFER shares the memory with the
GPDATA_BUFFER. Therefore it is not possible to use both
features at the same time.
• Not all CSRs or features of a particular camera model can
be used with the parameter list feature.
