FireWire
PIKE Technical Manual V5.1.2
43
Example1: 1394b bandwidth of PIKE cameras
Example 2: More than one PIKE camera at full speed
Due to the fact that one Pike camera can, depending on its settings, saturate a
32-bit PCI bus, you are advised to use either a PCI Express card and/or multiple
64-bit PCI bus cards, if you want to use 2 or more Pike cameras simultaneously
(see the following table).
www

ExpressCard is a new standard set by PCMCIA.
For more information visit:
http://www.expresscard.org/web/site/
PIKE model Resolution Frame rate Bandwidth
Pike F-032 B/C VGA 208 fps 62.5 MByte/s
Pike F-100 B/C 1 megapixel 60 fps 57.6 MByte/s
Pike F-145 B/C 1.4 megapixel 30 fps 41.4 MByte/s
Pike F-210 B/C 2.1 megapixel 31 fps 62.5 MByte/s
Pike F-421 B/C 4 megapixel 15 fps 62.5 MByte/s
Pike F-505 B/C 5 megapixel 13 fps 62.5 MByte/s
Pike F-1100 B/C 10.7 megapixel 2.6 fps (single-tap)
4.9 fps (dual-tap)
26.6 MByte/s
50.0 MByte/s
Pike F-1600 B/C 15.8 megapixel 1.7 fps (single-tap)
3.1 fps (dual-tap)
25.7 MByte/s
46.8 MByte/s
Table 6: Bandwidth of Pike cameras
Note

All data are calculated using Raw8 / Mono8 color mode. Higher
bit depths or color modes will double or triple bandwidth
requirements.
# cameras PC hardware required
1 Pike camera at full speed 1 x 32-bit PCI bus card (85 MByte/s)
2 or more Pike cameras at full speed PCI Express card and/or
Multiple 64-bit PCI bus cards
Table 7: Required hardware for multiple camera applications
