Description of the data path
PIKE Technical Manual V5.1.2
182
Binning and sub-sampling access
The binning and sub-sampling modes described in the last two chapters are only
available as pure binning or pure sub-sampling modes. A combination of both
is not possible.
As you can see there is a vast amount of possible combinations. But the number
of available Format_7 modes is limited and lower than the possible combina-
tions.
Thus access to the binning and sub-sampling modes is implemented in the fol-
lowing way:
• Format_7 Mode_0 is fixed and can not be changed
• A maximum of 7 individual AVT modes can be mapped to Format_7
Mode_1 to Mode_7

(see Figure 103: Mapping of possible Format_7 modes to F7M1...F7M7 on
page 183)
• Mappings can be stored via register (see Chapter Format_7 mode mapping
on page 362) and are uploaded automatically into the camera on camera
reset.
• The default settings (per factory) in the Format_7 modes are listed in the
following table
Format_7 PIKE monochrome cameras Format_7 PIKE color cameras Format_7
Mode_0 full resolution, no binning,

no sub-sampling
full resolution, no sub-sampling
Mode_1 2 x horizontal binning ---
Mode_2 2 x vertical binning ---
Mode_3 2 x full binning ---
Mode_4 2 out of 4 horizontal sub-sampling 2 out of 4 horizontal sub-sampling
Mode_5 2 out of 4 vertical sub-sampling 2 out of 4 vertical sub-sampling
Mode_6 2 out of 4 full sub-sampling 2 out of 4 full sub-sampling
Table 53: Default Format_7 binning and sub-sampling modes (per factory)
Note

• A combination of binning and sub-sampling modes is
not possible.

Use either pure binning or pure sub-sampling modes.
• The Format_ID numbers 0...31 in the binning /

sub-sampling list do not correspond to any of the
Format_7 modes.
