Configuration of the camera
PIKE Technical Manual V5.1.2
376
GPDATA_BUFFER
GPDATA_BUFFER is a general purpose register that regulates the exchange of
data between camera and host for:
• writing look-up tables (LUTs) into the camera
• uploading/downloading of the shading image
GPDATA_INFO Buffer size query
GPDATA_BUFFER indicates the actual storage range
Little endian vs. big endian byte order
• Read/WriteBlock accesses to GPDATA_BUFFER are recommended, to read
or write more than 4 byte data. This increases the transfer speed com-
pared to accessing every single quadlet.
• The big endian byte order of the 1394 bus is unlike the little endian byte
order of common operating systems (Intel PC). Each quadlet of the local
buffer, containing the LUT data or shading image for instance, has to be
swapped bytewise from little endian byte order to big endian byte order
before writing on the bus.
Register Name Field Bit Description
0xF1000FFC GPDATA_INFO --- [0..15] Reserved
BufferSize [16..31] Size of GPDATA_BUFFER
(byte)
0xF1001000
…
0xF10017FC
GPDATA_BUFFER
Table 196: Advanced register: GPData buffer
Note

• Read the BufferSize before using
• GPDATA_BUFFER can be used by only one function at a
time.
Bit depth little endian  big endian Description
8 bit L0 L1 L2 L3  L3 L2 L1 L0 L: low byte
H: high byte 16 bit L0 H0 L1 H1  H1 L1 H0 L0
Table 197: Swapped first quadlet at address offset 0
