Configuration of the camera
PIKE Technical Manual V5.1.2
323
Feature control error status register
Video mode control and status registers for
Format_7
Quadlet offset Format_7 Mode_0
The quadlet offset to the base address for Format_7 Mode_0, which can be read
out at F0F002E0h (according to
Table 142: Frame rate inquiry register on page
303) gives 003C2000h.
4 x 3C2000h = F08000h so that the base address for the latter ( Table 149:
Format_7 control and status register on page 323) equals

F0000000h + F08000h = F0F08000h.
Quadlet offset Format_7 Mode_1
The quadlet offset to the base address for Format_7 Mode_1, which can be read
out at F0F002E4h (according to
Table 142: Frame rate inquiry register on page
303) gives 003C2400h.
4 x 003C2400h = F09000h so that the base address for the latter ( Table 149:
Format_7 control and status register on page 323) equals

F0000000h + F09000h = F0F09000h.
Format_7 control and status register (CSR)
Offset Name Notes
640h Feature_Control_Error_Status_HI Always 0
644h Feature_Control_Error_Status_LO Always 0
Table 148: Feature control error register
Offset Name Notes
000h MAX_IMAGE_SIZE_INQ According to IIDC V1.31
004h UNIT_SIZE_INQ According to IIDC V1.31
008h IMAGE_POSITION According to IIDC V1.31
00Ch IMAGE_SIZE According to IIDC V1.31
010h COLOR_CODING_ID See note
014h COLOR_CODING_INQ According to IIDC V1.31
Table 149: Format_7 control and status register
