Camera interfaces
PIKE Technical Manual V5.1.2
129
Description of video data formats
The following tables provide a description of the video data format for the
different modes. (Source: IIDC V1.31; packed 12-bit mode: AVT)
Each component has 8-bit data.
Each component has 8-bit data.
U
(K+0)
Y
(K+0)
V
(K+0)
Y
(K+1)
U
(K+2)
Y
(K+2)
V
(K+2)
Y
(K+3)
U
(K+4)
Y
(K+4)
V
(K+4)
Y
(K+5)
U
(K+Pn-6)
Y
(K+Pn-6)
V
(K+Pn-6)
Y
(K+Pn-5)
U
(K+Pn-4)
Y
(K+Pn-4)
V
(K+Pn-4)
Y
(K+Pn-3)
U
(K+Pn-2)
Y
(K+Pn-2)
V
(K+Pn-2)
Y
(K+Pn-1)
Table 36: YUV8 (4:2:2) format: Source: IIDC V1.31
U
(K+0)
Y
(K+0)
Y
(K+1)
V
(K+0)
Y
(K+2)
Y
(K+3)
U
(K+4)
Y
(K+4)
Y
(K+5)
V
(K+4)
Y
(K+6)
Y
(K+7)
U
(K+Pn-8)
Y
(K+Pn-8)
Y
(K+Pn-7)
V
(K+Pn-8)
Y
(K+Pn-6)
Y
(K+Pn-5)
U
(K+Pn-4)
Y
(K+Pn-4)
Y
(K+Pn-3)
V
(K+Pn-4)
Y
(K+Pn-2)
Y
(K+Pn-1)
Table 37: YUV8 (4:1:1) format: Source: IIDC V1.31
