Filter and lenses
PIKE Technical Manual V5.1.2
48
Camera lenses
AVT offers different lenses from a variety of manufacturers. The following table
lists selected image formats depending on camera type, distance and the focal
length of the lens.
Note

All values listed in the following tables are theoretical and
therefore only approximate values (focal length and field of
view).
Focal length

for type 1/3 sensors

PIKE F-032
Distance = 0.5 m Distance = 1 m
4.8 mm 0.38 m x 0.5 m 0.75 m x 1 m
8 mm 0.22 m x 0.29 m 0.44 m x 0.58 m
12 mm 0.15 m x 0.19 m 0.29 m x 0.38 m
16 mm 11 cm x 15 cm 22 cm x 29 cm
25 mm 6.9 cm x 9.2 cm 14 cm x 18 cm
35 mm 4.8 cm x 6.4 cm 9.6 cm x 13 cm
50 mm 3.3 cm x 4.4 cm 6.6 cm x 8.8 cm
Table 9: Focal length vs. field of view (PIKE F-032)
Focal length

for type 2/3 sensors

PIKE F-100/F-145/F-505
Distance = 0.5 m Distance = 1 m
4.8 mm 0.7 m x 0.9 m 1.4 m x 1.9 m
8 mm 0.4 m x 0.5 m 0.8 m x 1.1 m
12 mm 0.27 m x 0.36 m 0.54 m x 0.72 m
16 mm 0.2 m x 0.27 m 0.4 m x 0.54 m
25 mm 13 cm x 17 cm 26 cm x 34 cm
35 mm 8.8 cm x 12 cm 18 cm x 24 cm
50 mm 6 cm x 7.9 cm 12 cm x 17 cm
Table 10: Focal length vs. field of view (PIKE F-100/F-145/F-505)
