Configuration of the camera
PIKE Technical Manual V5.1.2
363
Example
To map the internal Format_7 Mode_19 to the visible Format_7 Mode_1, write
the decimal number 19 to the above listed F7MODE_1 register.
Note

For available Format_7 modes see Figure 103: Mapping of pos-
sible Format_7 modes to F7M1...F7M7 on page 183.
Setting the F7MODE_x register to:
• -1 forces the camera to use the factory defined mode
• -2 disables the respective Format_7 mode (no mapping is
applied)
After setup of personal Format_7 mode mappings you have to
reset the camera. The mapping is performed during the camera
startup only.
