Video formats, modes and bandwidth
PIKE Technical Manual V5.1.2
236
Video formats, modes and bandwidth
The different Pike models support different video formats, modes and frame
rates.
These formats and modes are standardized in the IIDC (formerly DCAM) specifi-
cation.
Resolutions smaller than the generic sensor resolution are generated from the
center of the sensor and without binning.
Note
•
The maximum frame rates can only be achieved with
shutter settings lower than 1/framerate. This means that
with default shutter time of 40 ms, a camera will not
achieve frame rates higher than 25 frames/s. In order to
achieve higher frame rates, please reduce the shutter
time proportionally.
•
The following tables assume that bus speed is
800 Mbit/s. With lower bus speeds (e.g. 400, 200 or 100
Mbit/s) not all frame rates may be achieved.
•
For information on bit/pixel and byte/pixel for each color
mode see
Note
The following Format_7 tables show default Format_7 modes
without Format_7 mode mapping.
•
see
Figure 103: Mapping of possible Format_7 modes to
•
see Chapter
Note
H-binning means horizontal binning.
V-binning means vertical binning.
Full binning (H+V) means horizontal + vertical binning
2 x binning means: 2 neighboring pixels are combined.
4 x binning means: 4 neighboring pixels are combined.
•
Binning average means: signals form adjacent pixels are
combined by averaging.
•
Binning increases signal-to-noise ratio (SNR), but
decreases resolution.
