Description of the data path
PIKE Technical Manual V5.1.2
199
Changing color correction coefficients
You can change the color-correction coefficients according to your own needs.
Changes are stored in the user settings.
To change the color-correction coefficients in SmartView, go to Adv3 tab.
Switch color correction on/off
Color correction can also be switched off in YUV mode:
Note

• A number of 1000 equals a color correction coefficient of
1.
• To obtain an identity matrix set values of 1000 for the
diagonal elements an 0 for all others. As a result you get
colors like in the RAW modes.
• The sums of all rows should be equal to each other. If not,
you get tinted images.
• Color correction values range -1000 ... +2000 and are
signed 32 bit.
• In order for white balance to work properly ensure that
the row sum equals 1000.
• Each row should sum up to 1000. If not, images are less
or more colorful.
• The maximum row sum is limited to 2000.
Note

Configuration
To configure the color-correction coefficients in an advanced
register: See
Table 169: Advanced register: Color correction on
page 350.
Note

Configuration
To configure this feature in an advanced register: See Table
169: Advanced register: Color correction on page 350.
Note

Color correction is deactivated in RAW mode.
