Video formats, modes and bandwidth
PIKE Technical Manual V5.1.2
277
AOI frame rates maxBPP=11000,
single
-tap, sub-sampl.
Figure 134: Pike F-1100 [width=4008] (maxBPP=11000, single-tap, sub-sampling)
AOI height
CCD
RAW8
RAW12
RAW16
YUV411
YUV422
RGB8
2672
1.811
1.8
1.8
1.8
1.8
1.8
1.8
2048
2.320
2.3
2.3
2.3
2.3
2.3
2.3
1200
3.753
3.7
3.7
3.7
3.7
3.7
3.7
1024
4.305
4.3
4.3
4.3
4.2
4.2
4.2
960
4.548
4.5
4.5
4.5
4.5
4.5
4.5
600
6.687
6.6
6.6
6.6
6.6
6.6
6.6
480
7.895
7.8
7.8
7.8
7.8
7.8
7.8
300
10.90
10.9
10.9
10.9
10.8
10.8
10.8
240
12.48
12.4
12.4
12.4
12.4
12.4
12.4
Figure 135: Pike F-1100 [width=4008] (maxBPP=11000, single-tap, sub-sampling)
Note
CCD = theoretical max. frame rate (in fps) of CCD
maxBPP: for explanation and configuration see Chapter
Frame rate = f(AOI height) *PIKE F-1100* (max BPP = 11000; single-tap; sub-sampling)
0
2
4
6
8
10
12
14
16
18
20
22
24
0
200
400
600
800
1000
1200
1400
1600
1800
2000
2200
2400
2600
2800
AOI height / pixel
Fr
ame r
a
te / fps
RAW8
RAW12, YUV411
RAW16, YUV422
RGB8
CCD
