Configuration of the camera
PIKE Technical Manual V5.1.2
345
Frame information
This register can be used to double-check the number of images received by the
host computer against the number of images which were transmitted by the
camera. The camera increments this counter with every FrameValid signal. This
is a mirror of the frame counter information found at 0xF1000610.
The FrameCounter is incremented when an image is read out of the sensor.
The FrameCounter does not indicate whether an image was sent over the IEEE
1394 bus or not.
Input/output pin control
Register Name Field Bit Description
0xF1000270 FRAMEINFO Presence_Inq [0] Indicates presence of this fea-
ture (read only)
ResetFrameCnt [1] Reset frame counter
--- [1..31] Reserved
0xF1000274 FRAMECOUNTER FrameCounter [0..31] Number of captured frames
since last reset
Table 164: Advanced register: Frame information
Note

• See Chapter Input/output pin control on page 117
• See Chapter IO_INP_CTRL 1-2 on page 118
• See Chapter IO_OUTP_CTRL 1-4 on page 122
• See Chapter Output modes on page 123
