Configuration of the camera
PIKE Technical Manual V5.1.2
369
Smear reduction (not Pike F-1100/1600)
To enable/disable smear reduction use the following register(s):
Defect pixel correction
In the following the abbreviation DPC for Defect Pixel Correction will be used.
To enable/disable and configure defect pixel correction use the following reg-
ister(s):
Register Name Field Bit Description
0xF1000440 LOW_SMEAR Presence_Inq [0] Indicates presence of this feature
(read only)
--- [1..5] Reserved
ON_OFF [6] Smear reduction on/off
--- [7..31] Reserved
Table 190: Advanced register: Smear reduction
Register Name Field Bit Description
0xF1000460 DEFECT_PIXEL_CORRECTION_CTRL Presence_Inq [0] Indicates presence of this
feature (read only)
--- [1..5] Reserved
ON_OFF [6] Defect pixel correction
(DPC) on/off
--- [7..31] Reserved
0xF1000464 DEFECT_PIXEL_CORRECTION_MEM Presence_Inq [0] Indicates presence of this
feature (read only)
--- [1] Reserved
EnaMemWR [2] Enable WR access (from host
to μC)
EnaMemRD [3] Enable RD access (from μC to
host)
--- [4..9] Reserved
Number

DefectColumn
[10..17] Number of current defect
columns (6 byte / column)
Number

DefectPixel
[18..31] Number of current defect
pixels (4 byte / pixel)
Table 191: Advanced register: Defect pixel correction
