Test images, Table 159: advanced register: test image – ALLIED Vision Technologies Pike F-1600 User Manual
Page 337
Configuration of the camera
PIKE Technical Manual V5.1.2
337
Test images
Bit [8] to [14] indicate which test images are saved. Setting bit [28] to [31]
activates or deactivates existing test images.
By activating any test image the following auto features are automatically dis-
abled:
•
auto gain
•
auto shutter
•
auto white balance
Register
Name
Field
Bit
Description
0xF1000210
TEST_IMAGE
Presence_Inq
[0]
Indicates presence of this feature
(read only)
---
[1..7]
Reserved
Image_Inq_1
[8]
Presence of test image 1
0: N/A
1: Available
Image_Inq_2
[9]
Presence of test image 2
0: N/A
1: Available
Image_Inq_3
[10]
Presence of test image 3
0: N/A
1: Available
Image_Inq_4
[11]
Presence of test image 4
0: N/A
1: Available
Image_Inq_5
[12]
Presence of test image 5
0: N/A
1: Available
Image_Inq_6
[13]
Presence of test image 6
0: N/A
1: Available
Image_Inq_7
[14]
Presence of test image 7
0: N/A
1: Available
---
[15..27] Reserved
TestImage_ID
[28..31] 0: No test image active
1: Image 1 active
2: Image 2 active
…
Table 159: Advanced register: Test image
