Appendices
A-8
CP1E CPU Unit Instructions Reference Manual(W483)
S
T
U
W
X
Mne-
monic
Instruction
FUN
No.
Upward
differen-
tiation
Downward
differentia-
tion
Immediate
refreshing
specifica-
tion
Page
SBN
SUBROU-
TINE
ENTRY
092
---
---
---
2-295
SBS
SUBROU-
TINE CALL
091
@SBS
---
---
2-290
SCL
SCALING
194
@SCL
---
---
2-276
SCL2
SCALING 2
486
@SCL2
---
---
2-280
SCL3
SCALING 3
487
@SCL3
---
---
2-284
SDEC
7-SEG-
MENT
DECODER
078
@SDEC
---
---
2-354
SET
SET
---
@SET
%SET
!SET
2-29
SETA
MULTIPLE
BIT SET
530
@SETA
---
---
2-31
SETB
SINGLE BIT
SET
532
@SETB
---
!SETB
2-33
SFT
SHIFT
REGISTER
010
---
---
---
2-127
SFTR
REVERS-
IBLE SHIFT
REGISTER
084
@SFTR
---
---
2-129
SLD
ONE DIGIT
SHIFT LEFT
074
@SLD
---
---
2-139
SNXT
STEP
START
009
---
---
---
2-342
SPED
SPEED
OUTPUT
885
@SPED
---
---
2-319
SRD
ONE DIGIT
SHIFT
RIGHT
075
@SRD
---
---
2-139
STC
SET
CARRY
040
@STC
---
---
2-398
STEP
STEP
DEFINE
008
---
---
---
2-342
SWAP
SWAP
BYTES
637
@SWAP
---
---
2-253
Mne-
monic
Instruction
FUN
No.
Upward
differen-
tiation
Downward
differentia-
tion
Immediate
refreshing
specifica-
tion
Page
TCMP
TABLE
COMPARE
085
@TCMP
---
---
2-101
TIM
HUNDRED-
MS TIMER
---
---
---
---
2-66
TIMH
TEN-MS
TIMER
015
---
---
---
2-69
TIMHX
TEN-MS
TIMER
551
---
---
---
2-69
TIML
LONG
TIMER
542
---
---
---
2-77
TIMLX
LONG
TIMER
553
---
---
---
2-77
TIMX
HUNDRED-
MS TIMER
550
---
---
---
2-66
TMHH
ONE-MS
TIMER
540
---
---
---
2-72
TMHHX
ONE-MS
TIMER
552
---
---
---
2-72
TPO
TIME-PRO-
PORTION-
ALOUTPUT
685
---
---
---
2-269
TR
TR Bits
---
---
---
---
2-20
TTIM
ACCUMU-
LATIVE
TIMER
087
---
---
---
2-74
TTIMX
ACCUMU-
LATIVE
TIMER
555
---
---
---
2-74
TXD
TRANSMIT
236
@TXD
---
---
2-369
Mne-
monic
Instruction
FUN
No.
Upward
differen-
tiation
Down-
ward dif-
ferentiatio
n
Immedi-
ate
refreshing
specifica-
tion
Page
UP
CONDI-
TION ON
521
---
---
---
2-17
Mne-
monic
Instruction
FUN
No.
Upward
differen-
tiation
Downward
differentia-
tion
Immediate
refreshing
specifica-
tion
Page
WDT
EXTEND
MAXIMUM-
CYCLE
TIME
094
@WDT
---
---
2-399
WSFT
WORD
SHIFT
016
@WSFT
---
---
2-131
Mne-
monic
Instruction
FUN
No.
Upward
differen-
tiation
Downward
differentia-
tion
Immediate
refreshing
specifica-
tion
Page
XCHG
DATA
EXCHANGE
073
@XCHG
---
---
2-121
XFER
BLOCK
TRANSFER
070
@XFER
---
---
2-117
XFRB
MULTIPLE
BIT TRANS-
FER
062
@XFRB
---
---
2-115
XORL
DOUBLE
EXCLU-
SIVE OR
612
@XORL
---
---
2-214
XORW
EXCLU-
SIVE OR
036
@XORW
---
---
2-214
Mne-
monic
Instruction
FUN
No.
Upward
differen-
tiation
Downward
differentia-
tion
Immediate
refreshing
specifica-
tion
Page
