2 Instructions

2-218

CP1E CPU Unit Instructions Reference Manual(W483)

Special Math Instructions

APR

Applicable Program Areas

Operands

Sine Function

Cosine Function

Instruction

Mnemonic

Variations

Function

code

Function

ARITHMETIC PROCESS

APR

@APR

069

Calculates the sine, cosine, or a linear extrapola-
tion of the source data.

Symbol

APR

Area

Step program areas

Subroutines

Interrupt tasks

Usage

OK

OK

OK

Operand

Description

Data type

Size

C

Control word

UINT

Variable

S

Source data

WORD

1

R

Result word

WORD

1

• Sine Function (C=0000)

When C is 0000, APR(069) calculates the SIN(S) and writes
the result to R. The range for S is 0000 to 0900 BCD (0.0

°

to

90.0

°

) and the range for R is 0000 to 9999 BCD (0.0000 to

0.9999). The remainder of the result beyond the fourth deci-
mal place is eliminated.

• Cosine Function (C=0001)

When C is 0001, APR(069) calculates the COS(S) and writes
the result to R. The range for S is 0000 to 0900 BCD (0.0

°

to

90.0

°

) and the range for R is 0000 to 9999 BCD (0.0000 to

0.9999). The remainder of the result beyond the fourth deci-
mal place is eliminated.

Note The actual result for SIN(90

°

) and COS(0

°

) is 1, but 9999 (0.9999) will be output to R.

C: Control word

S: Source word

R: Result word

APR(069)

C

S

R

Operand

Value

Data range

C

0000 hex

---

S

0000 to 0900 (BCD)

0

°

to 90

°

R

0000 to 9999 (BCD)
9999 (BCD)

0.0000 to 0.9999

1.0000

Operand

Value

Data range

C

0001 hex

---

S

0000 to 0900 (BCD)

0

°

to 90

°

R

0000 to 9999 (BCD)
9999 (BCD)

0.0000 to 0.9999

1.0000
