1 Summary of Instructions
1-6 CP1E CPU Unit Instructions Reference Manual(W483)
Data Shift
Instructions SHIFT REGISTER SFT 010 Operates a shift register. 2-127
REVERSIBLE
SHIFT REGISTER SFTR/
@SFTR 084 Creates a shift register that shifts data to either the right or the left. 2-129
WORD SHIFT WSFT/
@WSFT 016 Shifts data between St and E in word units. 2-131
ARITHMETIC
SHIFT LEFT ASL/
@ASL 025
Shifts the contents of Wd one bit to the left.
2-133
ARITHMETIC
SHIFT RIGHT ASR/
@ASR 026 Shifts the contents of Wd one bit to the right. 2-134
ROTATE LEFT ROL/
@ROL 027 Shifts all Wd bits one bit to the left including the Carry Flag (CY). 2-135
ROTATE RIGHT ROR/
@ROR 028 Shifts all Wd bits one bit to the right including the Carry Flag (CY). 2-137
ONE DIGIT SHIFT
LEFT SLD/
@SLD 074 Shifts data by one digit (4 bits) to the left. 2-139
ONE DIGIT SHIFT
RIGHT SRD/
@SRD 075 Shifts data by one digit (4 bits) to the right. 2-139
SHIFT N-BITS LEFT NASL/
@NASL 580 Shifts the specified 16 bits of word data to the left by the specified number of
bits. 2-141
DOUBLE SHIFT
N-BITS LEFT NSLL/
@NSLL 582 Shifts the specified 32 bits of word data to the left by the specified number of
bits. 2-141
SHIFT N-BITS
RIGHT NASR/
@NASR 581 Shifts the specified 16 bits of word data to the right by the specified number of
bits. 2-144
DOUBLE SHIFT
N-BITS RIGHT NSRL/
@NSRL 583 Shifts the specified 32 bits of word data to the right by the specified number of
bits. 2-144
Increment/
Decrement
Instructions INCREMENT
BINARY ++/
@++ 590 Increments the 4-digit hexadecimal content of the specified word by 1. 2-147
DOUBLE INCRE-
MENT BINARY ++L/
@++L 591 Increments the 8-digit hexadecimal content of the specified words by 1. 2-147
DECREMENT
BINARY --/
@-- 592 Decrements the 4-digit hexadecimal content of the specified word by 1. 2-150
DOUBLE DECRE-
MENT BINARY --L/
@--L 593 Decrements the 8-digit hexadecimal content of the specified words by 1. 2-150
INCREMENT BCD ++B/
@++B 594 Increments the 4-digit BCD content of the specified word by 1. 2-153
DOUBLE INCRE-
MENT BCD ++BL/
@++BL 595 Increments the 8-digit BCD content of the specified words by 1. 2-153
DECREMENT BCD --B/
@--B 596 Decrements the 4-digit BCD content of the specified word by 1. 2-156
DOUBLE DECRE-
MENT BCD --BL/
@--BL 597 Decrements the 8-digit BCD content of the specified words by 1. 2-156
Instrucion
Type
Instruction Mnemonic
FUN
No.
Function Page
