2 Instructions
2-192 CP1E CPU Unit Instructions Reference Manual(W483)
8-to-256 bit conversion
C: Control Word
Operand Specifications
Flags
Function
MLPX(076) can perform 4-to-16 bit or 8-to-256 bit conversions. Set the leftmost digit of C to 0 to specify
4-to-16 bit conversion and set it to 1 to specify 8-to-256 bit conversion.
S: Source Word R: First Result Word
D+15 to D: Decoding result of 1st digit of decoded digits
D+31 to D+16:
Decoding result of 2nd digit of decoded digits
Note The result words must be in the same data area.
Area
Word addresses Indirect DM addresses
Constants CF Pulse bits TR bits
CIO WR HR AR T C DM @DM *DM
S
OK OK OK OK OK OK OK OK OK
---
--- --- --- C OK
R ---
Name Label Operation
Error Flag P_ER • ON if C is not within the specified ranges.
• OFF in all other cases.
4-to-16 bit Conversion
When the leftmost digit of C is 0,
MLPX(076) takes the value of the speci-
fied digit in S (0 to F) and turns ON the
corresponding bit in the result word. All
other bits in the result word will be turned
OFF. Up to four digits can be converted.
S
8 15
Digit 1 Digit 0
0 7
Digits from the starting digit going left are
decoded
(Returns to digit 0 after digit 1)
C 1
8 11 12 15
l n
0 3 4 7
Conversion process
1: 8-to-256 bits (byte to 16-word range)
Always 0.
Number of digits/bytes to be converted
0 or 1 (1 or 2 bytes)
Specifies the first digit/byte to be converted
0 or 1 (byte 0 or 1)
S
n
l
1
1
m p 0 15
C 0 l n
p m
R
R+1
4-to-16 bit decoding
(Bit m of R is turned ON.)
n=2 (Start with third digit.)
R=1 (Convert 2 digits.)
