Omron SYSMAC CP CP1E-N@@D@-@ - Manual (Page 265)

2-229
2 Instructions
CP1E CPU Unit Instructions Reference Manual(W483)
F
loat
ing
-p
o
int
Math
In
stru
ctio
ns
2
Floating-point Math Instructions
The Floating-point Math Instructions convert data and perform floating-point arithmetic operations.
Data Format
Floating-point data expresses real numbers using a sign, exponent, and mantissa. When data is
expressed in floating-point format, the following formula applies.
Real number = (–1) s 2 e– 127 (1.f)
s: Sign
e: Exponent
f: Mantissa
The floating-point data format conforms to the IEEE754 standards. Data is expressed in 32 bits, as follows:
Number of Digits
The number of effective digits for floating-point data is seven digits for decimal.
Floating-point Data
The following data can be expressed by floating-point data:
• –
∞
• –3.402823
× 10 38 ≤ value ≤ –1.175494 Ч 10 – 38
• 0
• 1.175494
Ч 10 – 38 ≤ value ≤ 3.402823 × 10 38
• +
∞
• Not a number (NaN)
Special Numbers
The formats for NaN,
±∞, and 0 are as follows:
• NaN*:e = 255, f ≠ 0
• + ∞:e = 255, f = 0, s= 0
• – ∞:e = 255, f = 0, s= 1
• 0: e = 0, f = 0
* NaN (not a number) is not a valid floating-point number. Executing floating-point calculation instructions will not
result in NaN.
Data No. of bits Contents
s: sign 1 0: positive; 1: negative
e: exponent 8 The exponent (e) value ranges from 0 to 255. The actual exponent is the
value remaining after 127 is subtracted from e, resulting in a range of
–127 to 128. “e=0” and “e=255” express special numbers.
f: mantissa 23 The mantissa portion of binary floating-point data fits the formal 2.0 > 1.f ≥1.0.
e s f
31 30 23 22 0
Sign Exponent Mantissa
–1.175494 Ч 10 –38 1.175494 Ч 10 –38
– ∞ + ∞
–3.402823 Ч 10 38 3.402823 Ч 10 38 –1 0 1
