2 Instructions

2-158

CP1E CPU Unit Instructions Reference Manual(W483)

Symbol Math Instructions

+/+L

Applicable Program Areas

Operands

Operand Specifications

Instruction

Mnemonic

Variations

Function

code

Function

SIGNED BINARY ADD
WITHOUT CARRY

+

@+

400

Adds 4-digit (single-word) hexadecimal data
and/or constants.

DOUBLE SIGNED BINARY
ADD WITHOUT CARRY

+L

@+L

401

Adds 8-digit (double-word) hexadecimal data
and/or constants.

Symbol

+

+L

Area

Step program areas

Subroutines

Interrupt tasks

Usage

OK

OK

OK

Operand

Description

Data type

Size

+

+L

+

+L

Au

+:

Augend word

+L: First augend word

INT

DINT

1

2

Ad

+:

Addend word

+L: First addend word

INT

DINT

1

2

R

+:

Result word

+L: First result word

INT

DINT

1

2

Area

Word addresses

Indirect DM addresses

Constants

CF

Pulse bits

TR bits

CIO

WR

HR

AR

T

C

DM

@DM

*DM

Au, Ad

OK

OK

OK

OK

OK

OK

OK

OK

OK

OK

---

---

---

R

---

+(400)

R

Au

Ad

Au: Augend word

Ad: Addend word

R: Result word

+L(401)

R

Au

Ad

Au: 1st augend word

Ad: 1st addend word

R: 1st result word
