Page 150: Example of transferring multiple digits
2 Instructions
2-114
CP1E CPU Unit Instructions Reference Manual(W483)
Flags
Function
Precautions
If the number of digits being read or written exceeds the leftmost digit of S or D, MOVD(083) will wrap to
the rightmost digit of the same word.
Sample program
When CIO 0.00 is ON in the following example, four digits of data are copied from W0 to W100. The trans-
fer begins with the digit 1 of W0 and digit 0 of W100, in accordance with the control word’s value of 31.
Note After reading the leftmost digit of S (digit 3), MOVD(083) wraps to the rightmost digit (digit 0).
Example of transferring multiple digits
The following diagram shows examples of data transfers for various values of C.
Name
Label
Operation
Error Flag
P_ER
• ON if one of the first three digits of C is not within the specified range of 0 to 3.
• OFF in all other cases.
MOVB(082) copies the specified bit (n) from S
to the specified bit (m) in D. The other bits in
the destination word are left unchanged.
S
m
n
D
R
C
0
R
8
11
12
15
n
m
0
3
4
7
MOVD
W0
D300
W100
0.00
S
C
D
C D300
0
0
8
11
12
15
3
1
0
3
4
7
D: W100
4
1
8
11
12
15
2
3
3
2
1
0
3
2
1
0
0
3
4
7
S: W0
1
2
8
11
12
15
3
4
0
3
4
7
Digit no.
Digit no.
First digit in D: Digit 0
Number of digits: 3 (4 digits)
First digit in S: Digit 1
S
C
㧦211
D
S
C
㧦30
D
S
C
㧦312
D
S
C
㧦230
D
Digit 0
Digit 1
Digit 2
Digit 3
Digit 0
Digit 1
Digit 2
Digit 3
Digit 0
Digit 1
Digit 2
Digit 3
Digit 0
Digit 1
Digit 2
Digit 3
Digit 0
Digit 1
Digit 2
Digit 3
Digit 0
Digit 1
Digit 2
Digit 3
Digit 0
Digit 1
Digit 2
Digit 3
Digit 0
Digit 1
Digit 2
Digit 3
