SCL3
Operand Specifications
Flags
Function
SCL3(487) is used to convert the signed BCD data (the BCD data contains the absolute value and the
Carry Flag shows the sign) contained in the source word S into signed binary data and place the result
in the result word R according to the linear function defined by the slope (
∆X, ∆Y) and an offset. The
maximum and minimum conversion values are also specified. The address of the first word containing
∆X, ∆Y, the offset, the maximum conversion, and the minimum conversion is specified for the first
parameter word P1.
The sign of the result is indicated by the status of the Carry Flag (ON: negative, OFF: positive). Use
STC(040) and CLC(041) to turn the Carry Flag ON and OFF.
The following equations are used for the conversion.
• The offset and slope can be a positive value, 0, or a negative value. Using a negative slope enables
reverse scaling.
• The result will be rounded to the nearest integer.
• The source value in S is treated as an absolute BCD value and the sign is indicated by the Carry
Flag. The source value can thus be between –9999 and 9999.
• If the result is less than the minimum conversion value, the minimum conversion value will be output
as the result. If the result is greater than the maximum conversion value, the maximum conversion
value will be output.
Area
Word addresses
Indirect DM addresses
Constants
CF
Pulse bits
TR bits
CIO
WR
HR
AR
T
C
DM
@DM
*DM
S. P1,R
OK
OK
OK
OK
OK
OK
OK
OK
OK
---
---
---
---
Name
Label
Operation
Error Flag
P_ER
• ON if the contents of S is not BCD.
• ON if the contents of C+1 (
∆X) is not between 0001 and 9999 BCD.
• OFF in all other cases.
Equals Flag
P_EQ
• ON if the result is 0.
• OFF in all other cases.
Negative Flag
P_N
• ON when the MSB of the R (the result) is 1.
• OFF in all other cases.
R =
∆Y
× ((Binary conversion of S) + (Offset))
Binary conversion of
∆X
Note The slope of the line is
∆Y/∆X.
