20 CP1E CPU Unit Instructions Reference Manual(W483)
Related Manuals
The following manuals are related to the CP1E. Use them together with this manual.
Manual name Cat. No. Model numbers Application Contents
SYSMAC CP Series
CP1E CPU Unit Instruc-
tions Reference Manual
(this manual) W483 CP1E-E D -
CP1E-N D -
CP1E-NA D -
To learn program-
ming instructions in
detail Describes each programming instruction in
detail.
When programming, use this manual together
with the CP1E CPU Unit Software User’s Man-
ual (Cat. No. W480).
SYSMAC CP Series
CP1E CPU Unit Soft-
ware User’s Manual W480 CP1E-E D -
CP1E-N D -
CP1E-NA D -
To learn the software
specifications of the
CP1E PLCs Describes the following information for CP1E
PLCs.
• CPU Unit operation
• Internal memory
• Programming
• Settings
• CPU Unit built-in functions
• Interrupts
• High-speed counter inputs
• Pulse outputs
• Serial communications
• Other functions
Use this manual together with the CP1E CPU Unit Hardware User’s
Manual (Cat. No. W479) and Instructions Reference Manual (Cat. No.
W483).
SYSMAC CP Series
CP1E CPU Unit Hard-
ware User’s Manual W479 CP1E-E D -
CP1E-N D -
CP1E-NA D -
To learn the hard-
ware specifications
of the CP1E PLCs Describes the following information for CP1E
PLCs.
• Overview and features
• Basic system configuration
• Part names and functions
• Installation and settings
• Troubleshooting
Use this manual together with the CP1E CPU Unit Software User’s
Manual (Cat. No. W480) and Instructions Reference Manual (Cat. No.
W483).
CS/CJ/CP/NSJ Series
Communications Com-
mands Reference Man-
ual W342 CS1G/H-CPU H
CS1G/H-CPU -V1
CS1D-CPU H
CS1D-CPU S
CS1W-SCU -V1
CS1W-SCB -V1
CJ1G/H-CPU H
CJ1G-CPU P
CJ1M-CPU
CJ1G-CPU
CJ1W-SCU -V1
To learn communica-
tions commands for
CS/CJ/CP/NSJ-
series Controllers in
detail Describes
1) C-mode commands and
2) FINS commands in detail.
Read this manual for details on C-mode and
FINS commands addressed to CPU Units.
Note This manual describes commands addressed to CPU Units. It
does not cover commands addressed to other Units or ports (e.g.,
serial communications ports on CPU Units, communications ports
on Serial Communications Units/Boards, and other Communica-
tions Units).
SYSMAC CP Series
CP1L/CP1E CPU Unit
Introduction Manual W461 CP1L-L10D -
CP1L-L14D -
CP1L-L20D -
CP1L-M30D -
CP1L-M40D -
CP1L-M60D -
CP1E-E D -
CP1E-N D -
CP1E-NA D -
To learn the basic
setup methods of the
CP1L/CP1E PLCs Describes the following information for
CP1L/CP1E PLCs.
• Basic configuration and component names
• Mounting and wiring
• Programming, data transfer, and debugging
using the CX-Programmer
• Application program examples
