3-5
3 Instruction Execution Times and Number of Steps
CP1E CPU Unit Instructions Reference Manual(W483)
3-
1 CP1E CPU Un
it In
struc
tion
Ex
e
c
utio
n
T
imes and Num
ber
of
3
Comparison Instructions
Instruction
Mnemonic
FUN No.
Length
(steps)
ON execution
time (
µs)
Conditions
Input Comparison Instructions
(unsigned)
LD,AND,OR+=
300
4
9.3 ---
LD,AND,OR+
<>
305
LD,AND,OR+
<
310
LD,AND,OR+
<=
315
LD,AND,OR+
>
320
LD,AND,OR+
>=
325
Input Comparison Instructions
(double, unsigned)
LD,AND,OR+=+L
301
4
10.8 ---
LD,AND,OR+
<>+L
306
LD,AND,OR+
<+L
311
LD,AND,OR+
<=+L
316
LD,AND,OR+
>+L
321
LD,AND,OR+
>=+L
326
Input Comparison Instructions
(signed)
LD,AND,OR+=+S
302
4
9.4 ---
LD,AND,OR+
<>+S
307
LD,AND,OR+
<+S
312
LD,AND,OR+
<=+S
317
LD,AND,OR+
>+S
322
LD,AND,OR+
>=+S
327
Input Comparison Instructions
(double, signed)
LD,AND,OR+=+SL
303
4
10.9 ---
LD,AND,OR+
<>+SL
308
LD,AND,OR+
<+SL
313
LD,AND,OR+
<=+SL
318
LD,AND,OR+
>+SL
323
LD,AND,OR+
>=+SL
328
Time Comparison Instructions
=DT
341
4
14.5
---
<>DT
342
4
14.5 ---
343 4 14.4 --- <=DT 344 4 14.4 --- >DT 345 4 14.6 --- >=DT 346 4 14.6 --- COMPARE CMP 020 3 8.1 --- !CMP 020 7 49.1 --- DOUBLE COMPARE CMPL 060 3 9.5 --- SIGNED BINARY COMPARE CPS 114 3 8.1 --- !CPS 114 7 49.1 --- DOUBLE SIGNED BINARY COMPARE CPSL 115 3 9.5 --- TABLE COMPARE TCMP 085 4 61.1 --- UNSIGNED BLOCK COMPARE BCMP 068 4 107.6 --- AREA RANGE COMPARE ZCP 088 3 17.8 --- DOUBLE AREA RANGE COMPARE ZCPL 116 3 20.1 ---
