Wiring
3.7.2 PG Speed Control Card Terminal Blocks
3 - 16
Note 5 VDC and 12 VDC cannot be used at the same time.
J
PG-X2 (For Flux Vector Control Mode Only)
Table 3.6 PG-X2 Terminal Specifications
Terminal No. Contents Specifications
1 12 VDC (±5%), 200 mA max. (see note)
2 Power supply for pulse generator 0 VDC (GND for power supply)
3
pp y p g
5 VDC (±5%), 200 mA max. (see note)
4 A-phase + input terminal
TA1
5 A-phase -- input terminal
TA1
6 B-phase + input terminal
Line driver input (RS-422 level input)
7 B-phase -- input terminal
Line driver input (RS-422 level input)
Maximum response frequency: 300 kHz
8 Z-phase + input terminal
9 Z-phase -- input terminal
10 Common terminal 0 VDC (GND for power supply)
1 A-phase + output terminal
2 A-phase -- output terminal
3 B-phase + output terminal
Line driver output (RS 422 level output)
TA2 4 B-phase -- output terminal
Line driver output (RS-422 level output)
5 Z-phase + output terminal
6 Z-phase -- output terminal
7 Control circuit common Control circuit GND
TA3 (E) Shield connection terminal --
Note 5 VDC and 12 VDC cannot be used at the same time.
