2.4 External Dimensions and Mounting Dimensions
2 - 7
J
400-V Class (400 kW) and 575-V Class (600 kW) Inverter Panels
VARISPEED YASKAWA
570
2100
600
50
175
125
800
1400
30
770
5
615
770 max.
With door
open:
Generated
loss (W)
CIMR--G5Aj 4400 5600
Converter Module 2060 2060
Inverter Module 6860 8820
Control Unit 50 50
Discharge Resistor 120 200
Control Power Transformer 80 80
DC Reactor 370 370
Coupling Reactor 1480 1480
Total 11020 13060
2
