-86-
Switch (config)# evc ece 1 direction both evc 2 frame-type ipv4 inner-tag add dei 1
pcp 4 preserve type s-custom-tag vid 5 interface GigabitEthernet 1/3 outer-tag add
dei 0 mode enable pcp 2 vid 7 match dei any pcp any type c-tagged vid 6 policer 8
policy 9 pop 2
4.2.53 evc ece update
Command:
evc ece update direction {both | nni-to-uni | uni-to-nni} evc
{ | none} frame-type {any | ipv4 | ipv6} inner-tag { add {dei
0-1> | pcp | preserve | type [c-tag | none | s-custom-tag | s-tag] | vid
}, match {dei [ | any]| pcp [ |
any] | type [any | c-tagged | s-tagged | tagged | untagged] | vid [ |
any]} } interface [* | 10GigabitEthernet | GigabitEthernet] next [
1-4096> | last] outer-tag { add {dei | pcp | preserve |
type [c-tag | none | s-custom-tag | s-tag] | vid }, match {dei
[ | any]| pcp [ | any] | mode [disable | enable] | vid
[ | any] } policer { | discard | evc | none} policy
pop
ECE identifier
direction
Setup ECE direction
both
Bidirectional traffic flow
nni-to-uni
NNI-to-UNI traffic flow
uni-to-nni
UNI-to-NNI traffic flow
evc
EVC mapping
EVC identifier
none
Map to no EVC ID
frame-type
Setup matched frame type
any
Match any frame type
ipv4
Match IPv4 frames
ipv6
Match IPv6 frames
inner-tag
Setup inner tag options
add
Setup inner tag add properties.
dei
Setup added tag DEI
Added tag DEI
