-282-
af23
Assured Forwarding PHB AF23(DSCP 22)
af31
Assured Forwarding PHB AF31(DSCP 26)
af32
Assured Forwarding PHB AF32(DSCP 28)
af33
Assured Forwarding PHB AF33(DSCP 30)
af41
Assured Forwarding PHB AF41(DSCP 34)
af42
Assured Forwarding PHB AF42(DSCP 36)
af43
Assured Forwarding PHB AF43(DSCP 38)
be
Default PHB(DSCP 0) for best effort traffic
cs1
Class Selector PHB CS1 precedence 1(DSCP 8)
cs2
Class Selector PHB CS2 precedence 2(DSCP 16)
cs3
Class Selector PHB CS3 precedence 3(DSCP 24)
cs4
Class Selector PHB CS4 precedence 4(DSCP 32)
cs5
Class Selector PHB CS5 precedence 5(DSCP 40)
cs6
Class Selector PHB CS6 precedence 6(DSCP 48)
cs7
Class Selector PHB CS7 precedence 7(DSCP 56)
ef
Expedited Forwarding PHB(DSCP 46)
va
Voice Admit PHB(DSCP 44)
Default:
Disabled
Usage Guide:
To enabled the DSCP Ingress Classification
Example:
To configure the DSCP Ingress Classification (DSCP 36)
Switch# configure terminal
Switch (config)# qos map dscp-classify af42
4.2.184 qos map dscp-cos
Command:
qos map dscp-cos { | { be | af11 | af12 | af13 | af21 | af22 | af23 | af31 |
af32 | af33 | af41 | af42 | af43 | cs1 | cs2 | cs3 | cs4 | cs5 | cs6 | cs7 | ef | va } } cos
dpl
qos Quality of Service
map
Global QoS Map/Table
dscp-cos
Map for dscp to cos
S pecific DSCP
af11
Assured Forwarding PHB AF11(DSCP 10)
